UV 304/316 STERILIZER

Product Introduction

TPYE	Capacity M3/H	GPM	Power(W)	Inlet and outlet	Size(MM)
SMALL UV STERILIZER
SSUV-A01	0.23	1	8	G1/4"	220X50.8X70.8
SSUV-A02	0.45	2	14	G1/2"	350X63.5X88.5
SSUV-A03	0.68	3	17	G1/2"	360X63.5X88.5
SSUV-A06	1.35	6	21	G3/4"	490X63.5X88.5
SSUV-A08	1.8	8	28	G3/4"	600X63.5X88.5
SSUV-A12	2.7	12	40	G3/4"	906X63.5X88.5
BIG UV STERILIZER
SSUV-B5.5T40	5.5	24	40	G1"	906X101X201
SSUV-B8T40	8	35	40	DN40	906X159X359
SSUV-B12T40	12	53	40	DN50	906X159X359
SSUV-B15T40	15	66	40	DN65	906X219X420
SSUV-B12T80	12	53	80	DN50	906X101X271
SSUV-B20T80	20	88	80	DN65	906X159X359
SSUV-B25T80	25	110	80	DN65	906X159X359
SSUV-B15T120	15	66	120	DN65	1220X159X359
SSUV-B25T120	25	110	120	DN80	1220X159X359
SSUV-B45T120	45	198	120	DN80	1220X159X359
SSUV-B35T150	35	155	150	DN80	1630X159X319
SSUV-B50T150	50	220	150	DN100	1630X219X419
SSUV-B60T150	60	260	150	DN100	1630X219X419
SSUV-B80T150	80	352	150	DN100	1630X219X419
SSUV-B100T150	100	440	150	DN100	1630X219X419
SSUV-B125T150	125	550	150	DN150	1630X273X473
SSUV-B150T150	150	660	150	DN150	1630X325X525

Characteristics

♦304 and 316 stainless steel material for choosing.

♦The inside and outside of the main body is polished to enhance the ultracviolet irradiance,ensuring

♦that the sterilized material will not be sterilized and imcoplete during the sterilization process.

Aplication:

♦Water treatment for food processing industry,including fruit juice,milk,drink,beer,oil or canned food.

♦The water treatment for hospi or laboratory.

♦Drinking water treatment,such as house,office building,drinking water factory.hotel,restaurant

♦Chemical biopharmaceutical cooling water.

♦Swiming pool water treatment
