SLIM LINE G5/G13 GERMICIDAL UV LAMP

SLIM LINE G5/G13 T8 UV LAMP-SLIM LINE G5/G13 GERMICIDAL UV LAMP

Home > Products > SLIM LINE G5/G13 T8 UV LAMP >

SLIM LINE G5/G13 GERMICIDAL UV LAMP

Product Introduction

Type	H(MM)	Power(W)	Current(MA)	Voltage 50/60Hz	Voltage at High Freq	UV output at 254nm UW/CM2 W		Lamp base	Standard life type
T5 Diameter
G4T5	135	4	170	28	23	9	0.9	G5	8000
G6T5	212	6	160	42	34	16	1.6	G5	9000
G8T5	288	8	150	56	45	21	2.1	G5	9000
G11T5	212	11	330	49	40	22	2.2	G5	10000
G16T5	288	15	350	54	44	36	3.6	G5	10000
T8管径
G10T8	331	10	230	46	36	23	2.3	G13	10000
G15T8	437	15	340	51	44	47	4.7	G13	10000
G20T8	589	20	360	60	50	65	6.2	G13	10000
G25T8	437	25	600	43	41	70	7	G13	10000
G30T8	894	30	370	100	80	100	11.2	G13	10000
G36T8	1199	36	440	103	87	145	15.5	G13	10000
G55T8	894	55	780	87	70	160	17	G13	10000
G75T8	1199	75	850	110	85	220	26	G13	10000

Characteristics:

1.All of 2pins each end lamp made by Sailon Lighting can be replaced Philips's unite very well.

2.The inside wall of tube have been coated with a protective layer,so as to reduce the decay of UV light.

3.Amalgam technology is avalible rto choose for making the germicidal lamp with bigger power and long life

Application:

Aquarium sterilizer

Fish Pond dinsinfection

Air cleaning dinsinfection

Disinfection of Drinking water

UV filter
