4PINS ONE END STARDARD UVC LAM-4PINS ONE END STARDARD UVC LAMP
Home > Products > 4PINS ONE END STARDARD UVC LAM >
4PINS ONE END STARDARD UVC LAMP
Product Introduction

Type Tub Diameter(MM) S(mm) Power(W) Current(MA) Voltage 50/60Hz Voltage at High Freq UV output at 254nm
uw/cm2    w		 Standard life type Long life type
GPH118T5L 15 118 6 425 25 21 13 1.3 10000 13000
GPH150T5L 15 150 8 425 27 22 20 1.7 10000 13000
GPH212T5L 15 212 10 425 30 25 26 2.7 10000 13000
GPH287T5L 15 287 14 425 41 34 40 4 10000 13000
GPH303T5L 15 303 15 425 43 35 43 4.3 10000 13000
GPH357T5L 15 357 17 425 51 42 57 5.7 10000 13000
GPH436T5L 15 436 21 425 62 51 72 7.3 10000 13000
GPH550T5L 15 550 28 425 69 60 85 8.5 10000 13000
GPH793T5L 15 793 37 425 112 92 120 13 10000 13000
GPH843T5L 15 843 40 425 120 98 135 15 10000 13000
GPH1148T5L 15 1148 55 425 165 135 170 20 10000 13000
GPH1554T5L 15 1554 75 425 220 179 220 30 10000 13000
GPH1630T5L 15 1630 79 425 231 189 225 32 10000 13000


Characteristics:

1.All of H shape lamp made by Sailon Lighting can be replaced Philips's unite very well.

2.The inside wall of tube have been coated with a protective layer,so as to reduce the decay of UV light.

3.It's very easy to install.


Aplication:

Disinfection of swiming pool

Wast water treatment

Air cleaning dinsinfection

Disinfection of Drinking water

Air conditioning pipe disinfection
